EVOLIS Zenius Classic

Zenius is the one-stop solution to print high-quality single-sided cards, in monochrome or color, and encode technology cards, singly or in runs, for a variety of applications Printing performances
Color: from 120 to 150 cards per hour
Monochrome: from 400 to 500 cards per hour

Technical Specifications:

General printer specifications

Single-sided printing module, edge-to-edge printing
Color-dye sublimation and monochrome thermal transfer
300 dpi print head (11.8 dots/mm)
16 MB of RAM Card management and specifications

Choice of automated or manual feeding
Evolis High Trust® ribbons®

Maximize the quality and durability of printed cards, the lifespan of your print head and the overall reliability of your printer!

Automatic detection and setup
Ribbon embedded in a cassette for ease of use
Ribbon saver feature for monochrome printing
Display

LEDs
Graphic notifications from the printer2 : Empty feeder, cleaning, ”approaching end-of-ribbon” and “end-of-ribbon” warnings
Software

Supplied with the Evolis Premium Suite® for Windows:

Printer driver
Evolis Print Center for printer management and setup
Evolis Printer Manager for two-way notifications 3
Compatible with Windows™: XP SP3 32/64 ; Vista 32/64, W7 32/64, W8 32/64
Supplied with the eMedia CS Card Designer (30-day free trial to be downloaded from Mediasoft’s website)

Other OS: Mac 10.5 to 10.8, Linux upon request

Feeder capacity 50 cards (0.76 mm – 30 mil)
Output tray capacity 20 cards (0.76 mm – 30 mil)
Card thickness 0.25 to 0.76 mm (10 to 30 mil), calibration via the gauge
Types of cards Types of cards : All PVC, Composite PVC cards, PET, RPET, ABS1 and special varnished cards1
Card format ISO CR-80 – ISO 7810 (53.98 mm x 85.60 mm – 3.375” x 2.125”)
1 Under specific conditions

Ribbon capacity:
YMCKO 200 prints/roll
1/2 YMCKO 400 prints/roll
KO 600 prints/roll
Monochrome ribbon up to 1,000 prints/roll (Under specific conditions)
Hologram ribbon 400 prints/roll
Interfaces USB 1.1 (compatible 2.0)
Ethernet available as an option
Size (H x L x W) 195 mm (7.68”) x 205 mm (8.07″) x 310 mm (12.2”)
Weight 3.3 kg (7.3 lbs)

Sound (evaluated according to the ISO 7779 Standard)
Sound pressure level, LpAm, bystander position (YMCKO color mode)
When operating 46dB (A)
In sleep mode Background noise only
Safety
Support for Kensington Lock®
Data encryption for magnetic encoding (for the ‘Expert’ version or above)
Packaging content
Printer
CD-ROM with the printer driver and user manual
Cleaning kit
USB cable
Power supply and cords
Options & accessories
Available colors Fire Red or Grey Brown
Ethernet TCP-IP (for the ‘Expert’ version or above)
Encoding options can be combined, factory ordered or upgraded on-site with additional modules (expert version): Magnetic stripe encoder, smart card contact station, smart card encoder and contactless smart card encoder. Other encoders available upon request.
Eco-friendly design, certifications and statement of compliance
Sleep mode and reduced energy consumption
CE, FCC, IEC, VCCI, CCC, KC
ErP 2009/125/CE, ENERGY STAR, RoHS
Power
Power supply 100–240 V AC, 50–60 Hz, 1.8 A
Printer 24 V DC, 3 A
Environment
Min/max operating temperature 15° / 30°C (59° / 86°F)
Humidity 20% to 65% non-condensing
Min/max storage temperature –5° / +70°C (23° / 158°F)
Storage humidity 20 to 70% non-condensing
Operating ventilation Open air
Resident fonts
Arial 100, Arial Bold 100
Bar code Code 39, code 128, EAN 13, Interleaved 2 of 5
